MAINTENANCE
118
8. Before installing spark plugs, clean off any dirt on the spark
plug seats. Install plugs finger tight, and then tighten 1/4 turn
or torque to specifications.
Description Nm lb. in. lb. ft.
Spark plug 27 20
9. Push pencil coils into place over the spark plugs using a
twisting motion.
10.Secure coils with retained bolts. Torque to specifications.
Description Nm lb. in. lb. ft.
Bolts 8 71
11.Connect the six wiring harness connectors to pencil coil
connections.
a
b
c
3658
a - Wiring harness
connector
b - Pencil coil
c - Bolt
12.Reinstall rear and top cowls.
Fuses
The electrical wiring circuits on the outboard are protected from
overload by fuses in the wiring. If a fuse is blown, try to locate and
correct the cause of the overload. If the cause is not found, the fuse
may blow again.

Table of Contents

Other manuals for Mercury 200 VERADO

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 200 VERADO and is the answer not in the manual?

Mercury 200 VERADO Specifications

General IconGeneral
Engine Type4-Stroke
Gear Ratio1.85:1
Full Throttle RPM Range5800-6400 RPM
Fuel SystemElectronic Fuel Injection (EFI)
ExhaustThrough Prop
Horsepower200 HP
Fuel Induction SystemElectronic Fuel Injection (EFI)
Shaft Length20", 25"
StartingElectric
Fuel Type87 Octane
Cylinder ConfigurationInline-6
Cooling SystemWater-cooled with thermostat
