Mercury Sterndrive QSD 2.0 - Page 100

Section 5 - Maintenance
Page 92 90-8M0069751 eng APRIL 2012
2. Turn the steering wheel until the steering cable is fully extended. Lightly lubricate the exposed part of the cable.
a - Extended steering cable
Tube Ref No. Description Where Used Part No.
34
Special Lubricant 101 Steering cable 92-802865Q02
3. Lubricate the steering pin.
a - Steering pin
Tube Ref. No. Description Where Used Part No.
Synthetic Blend MerCruiser Engine Oil
SAE25W‑40
Steering pin 92‑883725K01
4. On dual engine boats: Lubricate the tie bar pivot points.
Tube Ref. No.
Description Where Used Part No.
Synthetic Blend MerCruiser Engine Oil
SAE25W‑40
Tie bar pivot points 92‑883725K01
5. Upon first starting the engine, turn the steering wheel several times to starboard and then port to ensure that the steering
system operates properly before getting underway.
a
6222
mc71904-1
a
