Section 5 - Maintenance
90-8M0069751 eng APRIL 2012 Page 57
3. Ensure that the rubber gasket is inside the gear lube monitor cap and install the cap. Do not overtighten.
a - Gear lube monitor cap
NOTE: When filling the entire sterndrive, see
Changing
.
Changing
1. Remove the gear lube monitor from the bracket.
a - Gear lube monitor bracket
b - Gear lube monitor and cap
c - Retaining strap
2. Empty the contents of the gear lube monitor into a suitable container.
3. Install the gear lube monitor in the bracket.
4.
Remove the propeller. See Propellers.
5.
Bravo One Models:
a. Lower the sterndrive to the full down position.
b. Remove the gear lube fill and drain plug and sealing washer.
c. Drain the gear lube into a suitable container
a - Fill and drain plug
b - Sealing washer
6.
Bravo Two models and Bravo Three models:
a. Raise the sterndrive to the full up position.
b. Remove the fill and drain plug and sealing washer.
a
19962
5500
c
b
a
a
mc79506-1
b
