Section 5 - Maintenance
90-8M0069751 eng APRIL 2012 Page 49
2. Add the specified oil to bring the oil level up to, but not over, the maximum mark on the dipstick.
a - Coolant oil cooler
b - Seawater oil cooler
Engine Coolant Oil Cooler
QSD 2.0 System Capacity Fluid Type Part Number
Engine oil (with filter) 5.85 L (6.20 US qt) 15W40 4‑cycle Diesel Engine Oil 92‑877695K1
Engine Seawater Oil Cooler
QSD 2.0 System Capacity Fluid Type Part Number
Engine oil (with filter) 6.00 L (6.30 US qt) 15W40 4‑cycle Diesel Engine Oil 92‑877695K1
IMPORTANT: When refilling the engine with oil always use the dipstick to confirm the oil level.
3. Install the oil fill cap.
Changing Oil and Filter
See the Maintenance Schedule for the change interval. You should change the engine oil before placing the boat in storage.
IMPORTANT: Change the engine oil when the engine is warm from operation. Warm oil flows more freely, carrying away more
impurities. Use only recommended engine oil. See Specifications.
1. Start the engine and allow it to warm up to normal operating temperature.
2. Stop the engine and allow some time for the oil to drain into the oil pan (approximately five minutes).
3. Remove the fitting from the end of crankcase oil drain hose.
4. Install the crankcase oil pump (order separately) onto the threaded fitting of the engine oil drain hose.
Engine oil removal (Engine cover removed to
provide access)
a - Engine oil drain hose
b - Engine oil cap
c - Crankcase oil pump
To Next Page
