2.6 Safety devices.
Meaning.
The microwave combination oven has several safety devices to protect the user from hazards. It is essential that all safety
devices are fitted and in working order when operating the appliance.
Item
Safety device
Function
Check
1
Panels can only be
removed using a
tool.
Prevents live parts from being touched
accidentally.
Prevents access to the moving fan from the
wiring compartment.
Check that the covers are in place and
secured.
2
Operating panel can
only be removed
using a tool.
Prevents live parts from being touched
accidentally.
Ensure that the operating panel is in
place and secured.
3
Door seal.
“Consumable Item”
Protects the user and outside environment
from steam leaking from the cavity.
Check the door seal regularly for damage
and replace it if required.
4
Appliance door.
Protects the user and the environment
from hot steam and microwave energy.
Check the door and hinges regularly for
damage.
5 (no
picture)
Door interlocks.
Ensures that the microwave system
cannot be powered on when the door is
open.
Check door switches:
Open the appliance door fully during
pre-heat or when the oven is at
temperature.
The Door Open message is displayed.
6 (no
picture)
Disconnection
device.
Installed by the customer close to the
appliance; easily visible and accessible, 1-
or 3-pole action, installed per regional
specifications.
Used to disconnect the appliance from the
power supply in case of danger.
Trip the disconnection device.
If a breaker is installed refer to the
manual for the correct specification.
Type D required.
7 (no
picture)
Internal fuses.
Prevent faulty components from drawing
too much current and causing a potential
fire hazard.
Ensure that the internal fuses are
correctly rated.
8 (no
picture)
Internal high
temperature
thermostats
Prevent faulty components from
generating too much heat and causing
potential fire hazard.
Ensure correct operation.
