Merrychef conneX
®
service and repair manual
30
3.2 Dimensional drawings
conneX
®
12e
Front view (door closed) Cavity dimensions (door closed)
Front view (door closed) Cavity dimensions (door open)
[16.02]
407.0
View from the top (door closed)
[21.38]
543.0 mm
[21.38]
543.0 mm
[24.1]
612mm
[6.7] 170mm
[6.52]
165.6mm
[12.24]
311mm
[13.56] 344.5mm
[31.9]
810mm
[6.81]
173mm
[1.78]
45.2mm
