20 Technical Bulletin—TC-9100 Universal Controller
Item Tag
(Cont.)
Type Description
OCN1 Bits 8…6
Output Type
000 = Output not used.
Hardware analog outputs only:
001 = Not used. (Was for solenoid valve driver module.)
010 = 0 to 10 VDC output.
Hardware digital outputs (triac) only:
011 = On/off output.
100 = DAT output.
101 = PAT output (also uses OCN2 – define OCN2 as
“output not used”).
110 = 2-stage output (also uses OCN2 – define OCN2
as “output not used”).
OCO1 Number
Output Module 1 Parameter .
When OCN1 is PAT = Full stroke time of actuator (sec.).
When OCN1 is DAT = Cycle time of actuator (sec.).
When OCN1 is 2-stage = Load rating of stage 1 (% of
module output).
OCN2 1 Byte
Output Module 2 Configuration .
Bits 5…1
Source of Module in binary code:
01010 (0A hex) = Output Module 1 (OCM1).
01011 (0B hex) = Output Module 2 (OCM2).
⇓
01111 (0F hex) = Output Module 6 (OCM6).
Bits 8…6
Output Type
000 = Output not used (or used with PAT or 2-stage
output defined in OCN1).
Hardware analog outputs only:
001 = Not used. (Was for solenoid valve driver module.)
010 = 0 to 10 VDC output.
Hardware digital outputs (triac) only:
011 = On/off output.
OCO2 Number
Output Module 2 Parameter .
When OCN1 is PAT = PAT dead-band (%).
When OCN1 is 2-stage = Switching differential (%).
OCN3 1 Byte
Output Module 3 Configuration .
Bits 5…1
Source of Module in binary code:
01010 (0A hex) = Output Module 1 (OCM1).
01011 (0B hex) = Output Module 2 (OCM2).
⇓
01111 (0F hex) = Output Module 6 (OCM6).
Bits 8…6
Output Type
000 = Output not used.
011 = On/off output.
100 = DAT output.
101 = PAT output (also uses OCN4 – define OCN4 as
“output not used”).
110 = 2-stage output (also uses OCN4 – define OCN4
as “output not used”).
Continued on next page...
