Technical Bulletin—TC-9100 Universal Controller 21
Item Tag
(Cont.)
Type Description
OCO3 Number
Output Module 3 Parameter .
When OCN3 is PAT = Full stroke time of actuator (sec.).
When OCN3 is DAT = Cycle time of actuator (sec.).
When OCN3 is 2-stage = Load rating of stage 1 (% of
module output).
OCN4 1 Byte
Output Module 4 Configuration .
Bits 5…1
Source of Module in binary code:
01010 (0A hex) = Output Module 1 (OCM1).
01011 (0B hex) = Output Module 2 (OCM2).
⇓
01111 (0F hex) = Output Module 6 (OCM6).
Bits 8…6
Output Type
000 = Output not used (or used with PAT or 2-stage
output defined in OCN3).
011 = On/off output.
OCO4 Number
Output Module 4 Parameter .
When OCN3 is PAT = PAT dead-band (%).
When OCN3 is 2-stage = Switching differential (%).
OCN5 1 Byte
Output Module 5 Configuration .
Bits 5…1
Source of Module in binary code:
01010 (0A hex) = Output Module 1 (OCM1).
01011 (0B hex) = Output Module 2 (OCM2).
⇓
01111 (0F hex) = Output Module 6 (OCM6).
Bits 8…6
Output Type
000 = Output not used.
011 = On/off output.
100 = DAT output.
101 = PAT output (also uses OCN6 – define OCN6 as
“output not used”).
110 = 2-stage output (also uses OCN6 – define OCN6 as
“output not used”).
111 = 3-speed fan control (also uses OCN6 and OCN7 –
define OCN6 and OCN7 as “output not used”).
OCO5 Number
Output Module 5 Parameter .
When OCN5 is PAT = Full stroke time of actuator (sec.).
When OCN5 is DAT = Cycle time of actuator (sec.).
When OCN5 is 2-stage = Load rating of stage 1 (% of
module output).
When OCN5 is 3-speed fan control = Fan speed Break Point
1 (% of module output, must be lower than Break Point 2).
Continued on next page...
