OPERATION
Table 2 Installation (continued)
Configuration
Configure the ZL6 Using ZENTRA Utility
On the ZL6, push the TEST button on the logger to ensure the Bluetooth
®
module is activated.
On the mobile device, open ZENTRA Utility.
Select the ZL6 to connect.
Select Configure and set the desired cellular data upload settings (for ZL6
and ZL6 Pro) and sensor measurement interval (Section2.3.2). For Wi-Fi
configuration see (Section4.1).
NOTE: Configuration using ZENTRA Utility for Mac
®
and Windows
®
is addressed in
Section2.2.1.
Field Installation
Select Location
Choose the desired location based on relevant details including: representative
field position for sensor installation, vegetation cover throughout the season,
distance from power lines, minimal livestock interference, etc.
For ZL6 and ZL6 Pro, orient the solar panel to give it the maximum amount of
sunlight. In the northern hemisphere this will typically mean the data logger will
face south; in the southern hemisphere this will typically mean the data logger
will face north.
NOTE: If the location is in an area where solar energy harvesting is minimal, alkaline
batteries will power the logger longer than the NiMH batteries when not being recharged
by the solar panel. The ZL6 does not charge alkaline batteries.
Check Communication Quality
Evaluate how surroundings may attenuate the cellular or Wi-Fi signals.
Large metallic objects, power lines, and plant canopies may block
communication signals.
Use ZENTRA Utility to check the communication of the cellular signal
(Section2.2.2) or Wi-Fi signal (Section4.7).
If the signal is low or the communication test fails, move to an alternative
location (sometimes moving only a few meters is sufficient).
Fasten Logger to Mounting Post
Use the loopholes on the back of the logger enclosure to mount the ZL6 to a
post using zip ties or a similar fastener (such as hose clamps).
Ensure the logger is installed in an upright position to reduce the possibility of
water entering the ZL6 enclosure.
NOTE: The ZL6 case is water resistant, not waterproof. In extremely wet environments or
environments with prolonged high humidity, place a desiccant packet inside the logger or
enclose the logger in a waterproof case.
