3
ZL6
2. OPERATION
This section explains the basic workflow of logger installation, logger configuration, and data
download. Please read all instructions before operating the ZL6 to ensure it performs to its
full potential. Consider testing the ZL6 and sensors in a lab or office prior to field installation
to verify the correct operation of the system.
The ZL6 can serve as a data collection station for as many as six sensors. It is designed for
plug-and-play setup with all METER sensors, including the ATMOS weather sensors, TEROS
soil moisture sensors, HYDROS water sensors, PHYTOS leaf sensors, and ECH
2
O soil moisture
sensors. Please refer to the individual sensor manuals for sensor installation instructions.
NOTE: To use TEROS 31 and TEROS 32 sensors with the ZL6 Basic, a reference barometer sensor must be added to the
logger. Contact Customer Support.
2.1 INSTALLATION
Follow the steps listed in Table2 to set up the ZL6 and start collecting data.
NOTE: Never immerse the ZL6 in liquids or bury the ZL6. This and other misuse, improper protection, or improper
installation may damage the ZL6 and void the warranty.
Table2 Installation
Tools Needed
Microsoft
®
Windows
®
or Apple
®
Mac
®
computer for ZENTRA Utility
Apple
®
iPhone
®
(iOS 9.0 or newer) or Google Android
TM
smartphone
(Android4.3 or newer) for ZENTRA Utility Mobile
Mounting post (or similar)
Preparation
Install ZENTRA Utility or ZENTRA Utility
To install ZENTRA Utility Mobile on a smartphone or tablet:
• Open the app store.
• Search for ZENTRA Utility.
• Download the application.
To install ZENTRA Utility on a computer:
• Navigate to the ZL6 webpage (metergroup.com/zl6-support).
• Click the appropriate ZENTRA Utility Installer link.
• Click through the ZENTRA Utility Installer wizard.
The installer automatically installs the necessary USB driver for the ZL6.
Install Batteries
Press the TEST button on the logger. The status lights will eventually settle to a
green short, single blink every 5 s, signaling it is ready for use.
