VIKING / VIKING COMBI
Rev. 2.0 (1.8.2017)
Technical specifi cations
Item Type Acces-
sory
Specifi cation
Overall dimensions incl. support pillar WxDxH 40,60 1047x730x900/1070 mm
Overall dimensions incl. support pillar WxDxH 80,100 1154x785x900/1070 mm
Overall dimensions incl. support pillar WxDxH 150,200 1360x945x900/1070 mm
Overall dimensions incl. support pillar WxDxH 300 1560x1165x900/1070 mm
Overall dimensions incl. support pillar WxDxH 400 1560x1165x1050/1220 mm
Support pillar dimensions LxDxH 150x250x865 mm
Distance needed behind the kettle 40 730 mm
Distance needed behind the kettle 60 820 mm
Distance needed behind the kettle 80,100 850 mm
Distance needed behind the kettle 150 895 mm
Distance needed behind the kettle 200 895 mm
Distance needed behind the kettle 300,400 1135 mm
Tilting height from outer shell to fl oor 40,60 455 mm
Tilting height from outer shell to fl oor 80,100 405 mm
Tilting height from outer shell to fl oor 150,200 420 mm
Tilting height from outer shell to fl oor 300 450 mm
Tilting height from outer shell to fl oor 400 440 mm
Maximum height of cover 40,60 1710 mm
Maximum height of cover 80,100 1800 mm
Maximum height of cover 150,200 1980 mm
Maximum height of cover 300 2100 mm
Maximum height of cover 400 2235 mm
Distance needed for service, left side 250 mm
Distance needed for service, right side 150 mm
Inner diameter 40, 60 472 mm
Inner diameter 80,100 545 mm
Inner diameter 150,200 744 mm
Inner diameter 300,400 944 mm
Material of inner jacket and bottom Acid proof stainless steel
AISI 316
Other parts of the kettle Stainless steel AISI 304
Weight with package 40 190 kg
Weight with package 60 200 kg
Weight with package 80 215 kg
Weight with package 100 255 kg
Weight with package 150 310 kg
Weight with package 200 335 kg
Weight with package 300 520 kg
Weight with package 400 620 kg
Weight 40 155 kg
Weight 60 165 kg
Weight 80 175 kg
Weight 100 185 kg
Weight 150 250 kg
Weight 200 270 kg
