VIKING / VIKING COMBI
Rev. 2.0 (1.8.2017)
Installation
6.7.2. Cooking mode (steam heated models)
Before the kettle is switched on, the kettle jacket control valve must be closed.
Do the following:
• Check that the kettle is in its upright position.
• Close the control valve by turning the handle to the horizontal position.
1. Control valve of steam jacket
2. Safety valve relief lever1. Pressure gauge
Beware of hot steam.
6.7.3. Checking the safety valve
Do the following steps in order to check the safety valve:
Electrically heated models
1. Do the checking when the kettle is empty.
2. Check the water level of the steam generator
3. Switch the kettle on by turning the power regulator to position 6.
4. Heat up the kettle until the pressure gauge (1) shows 1,5 bar pressure
Open the safety valve by cautiously lifting the relief lever (2) upwards. Now the safety valve should
open and the pressure gauge should indicate a lower value.
Steam heated models
1. Do the checking when the kettle is empty.
2. Switch the kettle on by turning the power regulator to position 6.
3. Heat up the kettle until the pressure gauge (1) shows 1,0 bar pressure
4. Open the safety valve by cautiously lifting the relief lever (2) upwards. Now the safety valve should
open and the pressure gauge should indicate a lower value.
