18
|
VIKING 4G E, S
Rev. 1.0 (29.1.2020)
Operation instructions
Then turn the handle aside. Make sure that the mixing tool is locked in its
place by trying to lift/pull it out of its place by
pulling at the mixer blade, for example.
It is easiest to attach the mixing tool to the mixer axle
when the kettle is in a tilted position. Push the ring on
the mixing tool into the kettle’s mixer axle and fi t the
mixing tool in place, while the lifting handle is straight
so that the locking device of the lifting handle sets in
the groove at the upper end of the mixer axle.
Manual operation of the mixer
1. Make sure that the emergency/stop button is not pressed down. If pressed, release it by turning it
clockwise until it jumps up.
2. Choose mixing in one direction by turning the mixing program selector switch (1) from position 0 to
position or choose auto-reverse mixing by turning this switch from position 0 to position .
3. Start the mixer with the mixing program selector switch (1) while the mixing speed regulator (2) is in
position 0. The mixer starts after turning the speed regulator to about position 15. If the speed regula-
tor is not in position 0 when turning the program selector, it must be turned to 0 and only after that
to 15 or more.
1. Mixing program selector switch
2. Mixing speed regulator
3. Mixer On indicator
P1
15
0
40
60
80
100
120
P2
0
123
