VIKING 4G E, S
Rev. 1.0 (29.1.2020)
Operation instructions
Operation of the pre-set mixing programs
The automatic mixing programs are preset and cannot be changed. The programs will start immediately
when the mixing program selector switch is turned to position P1 or P2.
You can at any time directly switch over from one program to another program.
It is possible that the mixer is not moving even if a mixing program is running. The mixer ON indicator
shows that a program is on.
1. Mixing program selector switch
3. Mixer ON indicator
Stopping the mixing and the preset programs
The manual operation of the mixer can be interrupted by turning the mixing program selector switch (1)
to position 0. The mixing programs can be interrupted by turning the mixing program selector switch to
position 0.
Pressing the emergency/stop button will immediately stop all mixing functions.
Mixing speeds
The mixing speed can be steplessly chosen between 20-110 rpm.
Auto-reverse function
In spite of the speed selected, the mixer will run 6 seconds clockwise and 6 seconds counterclockwise.
P1
15
0
40
60
80
100
120
P2
0
12
P1
15
0
40
60
80
100
120
P2
0
13
1. Mixing program selector switch
2. Mixing speed regulator
Description of the preset mixing programs
The purpose of use, different phases of the program and the mixing speeds are shown in the following
table.
Program No. phase Speed Seconds/direction Duration
P1 1 15 rpm 6 cw/6 ccw/6 cw/pause 2 min. Continuous
P2 2.1
2.2
2.4
2.4
60 rpm 2 cw/2 ccw 12 s
60 rpm 9 cw/3 ccw 1 min
80 rpm 9 cw/3 ccw 5 min
60 rpm 9 cw/3 ccw 4 min
Maximum amount of mixing
The turning force and mixing features of the mixer are designed to mix most food ingredients. There
might although be food ingredients with a consistency that requires decreasing the kettle contents or
adding liquid to improve the mixing result. The turning force is best in the range 20-60 rpm.
