1. Physical installation:
Installation type: …………………….
surface installation frame
………………………………………..
subsurface installation frame
………………………………………..
free standing
Free standing installation flanges: ……………………………………..
yes
no
Floor fixing bolts (min. 150mm and stainless steel) in surface ……..
standard
chemical
installation:
Single or group installation: ……………………………………………..
single
group
Installation frames filled with acrylic filling: ……………………………
yes
no
2. Important perimeter clearances of all kettles:
measurement:
Support pillar (left) height: …………………...
[mm]
(900mm)
Control pillar (right) height: …………………..
[mm]
(992mm)
From support/control pillar without front ……
[mm]
(Dim. M, see installation manual)
plate to back wall/obstacle:
Width from pillar to pillar: …………………….
[mm]
(L1 single/L2 group, see installation
manual)
Height for lid opening OK: ………………………………………………
yes
no
3. Levelling & tilting bearings
Free standing installation is made according to installation manual:
yes
no
N/A
Pillars and kettle are aligned vertically/horizontally: ………………….
yes
no
Tilting bearing locks are checked: ……………………………………...
yes
no
4. Electric connections
Measured voltages [V]: …………….
L1–L2
L1–L3
L2–L3
L1–N
L2–N
L3–N
N–PE
………………………………………..
Breaker size/fuse rating [A]: ………
Measured amps per phase [A]: …………………… L1
L2
L3
(Full heating, no mixing)
Kettle connected to equipotential bonding: ……………………………
yes
no
Indicated voltage on the rating plate corresponds with measured ….
yes
no
voltage:
