Installation/commissioning checklist
for Metos kettles
Confidential
PRINTED PAPER COPY IS UNCONTROLLED - PAPERITULOSTE ON VALVOMATON KOPIO
We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.
 Copyright 2019 Metos Oy Ab
5. Water connections
Cold/hot water supply equipped with non-return and shut-off valves: …….
yes
no
Cold-water dynamic pressure min. 250 kPa – max. 600 kPa;
measured value: ……………………………………..
[kPa]
Max. chloride (CL
-)
< 60mg/l (if higher → deionization treatment): …….
yes
no
Max. chlorine (CL
2
)
< 0,2mg/l (if higher
→ carbon filter treatment): ……
yes
no
Ph between 6,5 – 9,5: ………………………………………………………….
yes
no
Conductivity < 1000μS/cm: …………………………………………………….
yes
no
Water treatment system used: ………………………………………………...
yes
no
If yes, manufacturer/type: ……...
Water total hardness calculated from calcium (lime) and magnesium rate.
Too low total hardness rate can cause corrosion < 0,5 d° if chloride rate is high.
6. External cooling systems
Kettle connected with external cooling system (ice-bank etc.): ……………
yes
no
If yes, installation company: …...
If yes, kettle manometer value when cooling: ……
[bar]
(max. 1,3bar)
Kettle equipped with pressurized air emptying: ……………………………...
yes
no
If yes, kettle manometer value when emptying: ….
[bar]
(max. 1,3bar)
Measured cooling water flow: ………………………
[l/min]
7. Procedures after installation
Rotation direction of hydraulic tilting pump motor (counterclockwise): ……
yes
no
N/A
Kettle up/down end limit switches working (kettle empties) and adjusted: ..
yes
no
N/A
Mixer rotating direction checked (clockwise): ………………………………..
yes
no
N/A
Lid and safety grid switches OK: ………………………………………………
yes
no
Date and time (option) set and checked: ……………………………………..
yes
no
N/A
Safety valve test executed (electric heated → panel/direct steam → valve):
yes
no
8. Function test/commissioning:
All electrical connections and plugs are tight: ………………………………..
yes
no
All water connections tight and no leakages: ………………………………..
yes
no
All steam connections tight and no leakages (direct steam kettles): ……...
yes
no
Cooling media circulation tight and no leakages (if closed circuit): ………..
yes
no
All standard functions operational: ……………………………………………
yes
no
All additional functions/features operational (HACCP, cooling etc.): ……...
yes
no
Customer advised in daily cleaning routine: …………………………………
yes
no
User/customer advised in preventative maintenance ………………………
yes
no
(safety valve test executed 4 times/year etc.):
