Metos VIKING - Page 60

60
|
VIKING 4G E, S
Rev. 1.0 (29.1.2020)
Technical specifi cations
Document type
Document ID
Revision
Page(s)
Review
DOC000650
A
4(4)
Owner organization
Created by
Date
Status
Metos Manufacturing
2019-08-19
Ready
Country
Department
Document title
Approved by
Security level
FI
Installation/commissioning checklist
for Metos kettles
Confidential
PRINTED PAPER COPY IS UNCONTROLLED - PAPERITULOSTE ON VALVOMATON KOPIO
We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.
 Copyright 2019 Metos Oy Ab
9. Direct steam kettles:
Steam pressure regulator valve; set pressure: …..…...
[bar]
(max. 1bar)
Steam pressure regulator valve; distance from kettle:
[m]
(min. 15m) *)
*) If not pilot guided valve, min. 10m.
Steam trap (condensation remover) before kettle; …...
[m]
(max. 2m) **)
distance:
Steam line installed according to installation manual: ………………………
yes
no
Steam line safety valve set pressure: …………..……..
[bar]
(max. 1,3bar)
Steam line safety valve after regulator valve: ………………………………..
yes
no
Steam line particle filter: ………………………………………………………..
yes
no
Non-return valve steam line installed if cooling: ……………………………..
yes
no **)
Steam line insulated: ……………………………………………………………
yes
no
Free flow in condensation line: ………………………………………………..
yes
no **)
Condensation line going downwards, min. 3°: ……………………………….
yes
no **)
Non-return valve condensation line installed: ………………………………..
yes
no **)
**) If no, contact factory.
Comments:
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
Revision history
Revision
Page (P)
Chapter (C)
Description
Date
Name/
Department
A
-
Original version
2019-08-19
