MI 3309 BT DeltaPAT Instrument description
13
2.3. Back side
Figure 2.3: Back side
Legend:
1 Inserts for side belt
2 Battery compartment cover
3 Fixing screw for battery compartment cover
4 Back side information label
5 Holder for inclined position of the instrument
Figure 2.4: Battery compartment
Legend:
1 Battery cells Type HR 6 (size AA), rechargeable NiMH / NiCd
2 Serial number label
