MI 3309 BT DeltaPAT Technical specifications
19
3.3. Substitute leakage current
Range Resolution Accuracy
0.00 mA  9.99 mA
0.01 mA
10.0 mA  20.0 mA
0.1 mA
(5 % of reading + 3 digits)
Powered by............................... battery or mains
Open circuit voltage .................. <50 V AC at rated mains voltage
Short circuit current................... <40 mA
Pass levels:
Substitute leakage .................... 0.25 mA, 0.50 mA, 0.75 mA, 1.00 mA, 1.50 mA, 2.00 mA,
2,25 mA, 2.50 mA, 3.50 mA, 4.00 mA, 4.50 mA, 5.00 mA,
5.50 mA, 6.00 mA, 7.00 mA, 8.00 mA, 9.00 mA, 10.0 mA,
15.0 mA, ---- mA
Test duration............................. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, --- s
Displayed current...................... calculated to appliance nominal mains supply voltage
(110 V or 230 V)
Test terminals (Sub. leakage) ...LN (Test socket)  PE (Test socket)
LN (terminal)  PE (terminal) (for fixed installed
appliances)
LN (Test socket)  S/EB (probe)
LN (terminal)  S/EB (probe) (for fixed installed
appliances)
3.4. Substitute leakage – P current
Range Resolution Accuracy
0.00 mA  4.99 mA
0.01 mA
(5 % of reading + 3 digits)
Powered by............................... battery or mains
Open circuit voltage .................. <50 V AC at rated mains voltage
Short circuit current................... <40 mA
Pass levels:
Substitute leakage - P............... 0.25 mA, 0.50 mA, 0.75 mA, 1.00 mA, 1.50 mA, 2,00 mA,
--- mA
Test duration............................. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, --- s
Displayed current...................... calculated to appliance nominal mains supply voltage
(110 V or 230 V)
Test terminals (Sub. leakage-P)LN (Test socket)  S/EB (probe)
LN (terminal)  S/EB (probe) (for fixed installed
appliances)
