METREL DeltaPAT MI 3309 BT User Manual

MI 3309 BT DeltaPAT Technical specifications
21
3.8. PRCD and RCD testing
3.8.1. General RCD Trip-out time
Complete measurement range corresponds to EN 61557-6 requirements.
Maximum measuring times set according to selected reference for RCD testing.
Range Resolution Accuracy
0 ms  1999 ms (½I
N
)
0.1 ms
0 ms  300 ms (I
N
)
0.1 ms
3 ms
0 ms  40 ms (5I
N
)
0.1 ms
1 ms
Powered by..................... mains
Test current..................... ½I
N
, I
N
, 5I
N
(I
N
= 10 mA, 15 mA, 30 mA)
Start angle ...................... 0, 180, both
Test modes ..................... single, autotest
Test terminals MAINS terminal
Specified accuracy is valid for complete operating range.
3.8.2. Portable RCD trip-out time
Range Resolution Accuracy
0 ms  1999 ms(½I
N
)
0.1 ms
0 ms  300 ms (I
N
)
0.1 ms
3 ms
0 ms  40 ms (5I
N
)
0.1 ms
1 ms
Powered by..................... mains
Test current..................... ½I
N
, I
N
, 5I
N
(I
N
= 10 mA, 15 mA, 30 mA)
Start angle ...................... 0, 180, both
Test modes ..................... single, autotest
Test terminals Test socket – IEC test terminal
Specified accuracy is valid for complete operating range.
