The information section located in the right part of the display displays additional information related
to the selected function:
• symbol of connected or disconnected output terminals.
At the same time, a LED located above the OUTPUT button is lit.
• information about remote/local control of the calibrator. If the calibrator is controlled remotely, REM
is displayed. If the calibrator is controlled locally using the keyboard, LOCAL is displayed.
• information about the use of 50-turn coil (COIL x50) at the current output of the calibrator, if this
feature is turned on using the SETUP menu.
• information about the type of connected cable adapter, if used
• information about the grounding method of output terminals: GND I, GND U as set up using the
setup menu.
g) Information about the uncertainty of the output signal
This section displays the maximum error of the main value of the output signal. The value is calculated
using the main specification listed in the User’s Manual and it is displayed in %.
2 INPUT section
This section displays the values measured by the multimeter. The section includes following data:
h) Main value of measured signal
This line displays the measured value and the unit of measurement. If the input signals exceed the
permitted range, OVERFLOW is displayed.
i) Designation of selected function of the multimeter
Symbolic display of selected function of the multimeter: V DC, mA DC, mV DC, R 4W, Freq, T TC, T
RTD, SGS, ACAL.
3 Display buttons section
This line displays the symbolic descriptions which define the meaning of four related display buttons. The
respective meanings are as follows:
selection of signal shape
only for U, I, F functions
+/-
reversed polarity of output voltage and current
only for DC U, DC I
only for F, P-E functions
enter the calibration menu
selection of thermocouple sensor type
RTD type selection of resistance temperature sensor
only for T function
enter the frequency of the signal
select the unit of measurement
