168
*2
parameter includes non-linear distortion and non-harmonic noise
*3
valid for frequencies to 10 kHz
Function Shape
voltage range: 1 mV to 200 V
wave form: square, positive, negative, symmetrical, ramp A, ramp B, triangle
truncated sin with THD 13,45 %
peak value uncertainty: 0.3 % + 50 uV
displayed values: peak, effective
Minimum frequency for squarewave signals is 0.1 Hz, for all others 20 Hz.
27.1.2. Current
summary range DCI: 0 - 20 A (with current coil 140-50 to 1000A)
summary range ACI: 1 µA - 20 A (with current coil 140-50 to 1000 A)
internal ranges: 200 µA, 2 mA, 20 mA, 200 mA, 2 A, 20 A
frequency range: 20 Hz to 5 kHz bellow 200 mA
20 Hz to 1000 Hz bellow 20 A
DCI uncertainty
range % value + % range max. voltage V
0 µA - 200 µA
0.05 + 0.0 + 20 nA
3
200 µA - 2 mA
0.02 + 0.005
3
2 mA - 20 mA
0.01 + 0.003
3
20 mA - 200 mA
0.01 + 0.003
3
200 mA - 2 A
0.015 + 0.005
3
2 A - 20 A
0.02 + 0.010
1.5
ACI uncertainty
range % value + % range max voltage Vef % value + % range max voltage Vef
20 Hz - 1 kHz 1 kHz – 5 kHz
1 µA - 200 µA
0.15 + 0.0 + 20 nA
3
0.30 + 0.10 + 20 nA
3
200 µA - 2 mA
0.07 + 0.01
3
0.20 + 0.05
3
2 mA - 20 mA
0.05 + 0.005
3
0.20 + 0.05
3
20 mA – 200 mA
0.05 + 0.005
3
0.20 + 0.05
3
200 mA – 2 A
0.05 + 0.005
3
- -
- -
2 A - 20 A
0.10 + 0.03
1.5
- -
- -
range % value + % range max voltage Vef
5 kHz – 10 kHz
1 µA - 200 µA
- -
- -
200 µA - 2 mA
0.50 + 0.07
2
2 mA - 20 mA
0.50 + 0.07
2
20 mA - 200 mA
0.50 + 0.07
2
200 mA - 2 A
- -
- -
2 A - 20 A
- -
- -
When option 130-50, 140-50 Current Coil is used, add uncertainty 0.3% of the set current to the value specified in above table. Output
current is multiplied by factor 50.
Auxiliary parameters
range 200 uA 2 mA 20 mA 200 mA 2 A 10 A
maximal inductive load
400 uH
400 uH
400 uH
400 uH
200 uH
100 uH
THD
*1
0,2%
0,2%
0,2%
0,2%
0,2%
0,3%
*1
parameter includes non-linear distortion and non-harmonic noise
Function Shape
current range: 100 uA to 2 A
wave form: square, positive, negative, symmetrical, ramp A, ramp B, triangle
truncated sin with THD 13,45 %
peak value uncertainty: 0.3 % + 500 nA
