Metrix CX 1651 User Manual

169
displayed values: peak, effective
Minimum frequency for squarewave signals is 0.1 Hz, for all others 20 Hz.
27.1.3. Resistance
summary range: 0 Ω to 50 MΩ
Resistance uncertainty
resistance range uncertainty of value [%] current range
0 Ω - 100 Ω
0.03 + 10 mΩ
1 mA - 40 mA
100 Ω - 400 Ω
0.015
400 µA - 20 mA
400 Ω - 2 kΩ
0.015
100 µA - 4 mA
2kΩ - 10 kΩ
0.015
20 µA - 1 mA
10 kΩ - 40 kΩ
0.015
4 µA - 200 µA
40 kΩ - 200 kΩ
0.015
1 µA - 40 µA
200kΩ -1 MΩ
0.05
0.2 µA - 10 µA
1 MΩ - 4 MΩ
0.1
40 nA – 2 µA
4 MΩ - 20MΩ
0.2
10 nA – 500 nA
20 MΩ - 50MΩ
0.5
4 nA – 150 nA
Maximal allowed voltage on output terminals is 8 V
pp
. Uncertainty is valid for four-terminal connection with use of Option 70 or Option
140-41 Cable adapters. For two-wire connection from the terminals Hi-Lo na the front panel add to the specified uncertainty next +10
mOhm.
27.1.4. Capacitance
summary range: 0.9 nF to 50 µF
Capacitance uncertainty
range uncertainty of value [%] max. frequency
900 pF - 2.5 nF
0.5 + 15 pF
1000 Hz
2.5 nF - 10 nF
0.5 + 5 pF
1000 Hz
10 nF - 50 nF
0.5
1000 Hz
50 nF – 250 nF
0.5
1000 Hz
250 nF - 1 µF
0.5
500 Hz
1 µF – 2.5 µF
1
300 Hz
2.5 µF - 5 µF
1
300 Hz
5 µF – 10 µF
1.5
300 Hz
10 µF - 50 µF
2.0
300 Hz
Maximal allowed voltage on output terminals is 8 V
pp
.
27.1.5. AC and DC power/energy
summary voltage range: 0.2 V to 240 V
current capability of voltage output: depends on the voltage range
summary current range: 2 mA to 10 A
maximal voltage on current output: depends on the current range
power range: 0.0004 to 2.4 kVA
time period range: 1.1 s to 1999 s
frequency range: DC, 40 Hz to 400 Hz
DCV uncertainty
See table of DCV uncertainty.
DCI uncertainty
range % value + % range max. voltage [V]
2 mA - 20 mA
0.05 + 0.010
3
20 mA - 200 mA
0.05 + 0.005
3
200 mA - 2 A
0.05 + 0.005
3
2 A – 10 A
0.05 + 0.010
1.5
