MHM SYNCHROPRINT 5000 - Specifications

Operating Instructions Synchroprint 5000
Operating instructions SP5000 V1-0.docx Page 12 of 52
3.3. Specifications
Model/Type SP 8 SP 10 SP 12 SP 14
Number of pallets 8 10 12 14
Max. No. of print stations 6 8 10 12
Max. print area (standard format)
50 x 70cm
20" x 28"
50 x 70cm
20" x 28"
50 x 70cm
20" x 28"
50 x 70cm
20" x 28"
Max. print area (large format)***
70 x 100cm
28" x 39"
70 x 100cm
28" x 39"
70 x 100cm
28" x 39"
70 x 100cm
28" x 39"
Max. diameter (std' format) [cm/inch]
(Lg' format) [cm/inch]
460/181"
575/226"
505/199"
620/244"
550/217"
680/268"
600/236"
735/289"
Machine height [cm/inch]
185/72,8" 185/72,8" 185/72,8" 185/72,8"
Machine weight*
1800 kg
3970 lbs
2150 kg
4740 lbs
2300 kg
5070 lbs
2650 kg
5840 lbs
Ø air consumption [l/min.] 190 220 250 280
Minimum air pressure
Drive systems
Electrical Supply [V]
Connected load - machine base
Connected load - Squeegee drive
Ø power consumption [kWh] 0,9 1,05 1,2 1,35
Registration accuracy
Recommended frame/screen profile
Max. frame/screen size (O.D.)
Production capacity [pieces / h]**
75 x 110 cm / 30 x 42"
Large format 95 x 140 cm / 37 x 55"
40 x 40 mm / 1.57 x 1.57"
1000
8 bar / 116 p.s.i. (filtered, dry air only)
AC-Servo-Drive Index / Electric Squeegee Drive
3 x 210/400V, 50/60 Hz (+/- 5%)
2.5 kVA
0.4 kVA (each)
+/- 0.02 mm / +/- 0.00078"
Model/Type SP 16 SP 18 SP 20
Number of pallets 16 18 20
Max. No. of print stations 14 16 18
Max. print area (standard format only)
50 x 70cm
20" x 28"
50 x 70cm
20" x 28"
50 x 70cm
20" x 28"
Max. diameter [cm/inch]
640/252" 690/271" 730/287"
Machine height [cm/inch]
185/72,8" 185/72,8" 205/81"
Machine weight*
3000 kg
6615 lbs
3350 kg
7386 lbs
3650 kg
8047 lbs
Ø air consumption [l/min.] 310 340 370
Minimum air pressure
Drive systems
Electrical supply [V]
Connected load - machine base
Connected load - Squeegee drive
Ø power consumption [kWh] 1,5 1,65 1,8
Registration accuracy
Recommended frame/screen profile
Max. frame/screen size (O.D.)
Production capacity [pieces / h]**
900 800 700
75 x 110 cm / 30 x 42"
Large format 95 x 140 cm / 37 x 55"
8 bar / 116 p.s.i. (filtered, dry air only)
AC-Servo-Drive Index / Electric Squeegee Drive
3 x 210/400V, 50/60 Hz (+/- 5%)
0.4 kVA (each)
+/- 0.02 mm / +/- 0.00078"
40 x 40 mm / 1.57 x 1.57"
2.5 kVA
* …… Total weight (unpacked) with max. number of print stations
** ….. Single print stroke and medium length of stroke
*** … Special formats available upon request
