Operating Instructions Synchroprint 5000
Operating instructions SP5000 V1-0.docx Page 44 of 52
Display 3:
F1 Starts an “Index Measurement” of the tables. This is only necessary at machine
installation. Machine will detect distance between all stations for smooth movement.
F2 Not available at Synchroprint
F3 Optional function 2-Job-mode to print two separate print jobs simultaneously. More
information at Fehler! Verweisquelle konnte nicht gefunden werden.. “Fehler!
rweisquelle konnte nicht gefunden werden.”.
9.8.2. Manual
At Manual-mode with button “Start” one index and working cycle will be processed. An optional
foot switch provides the same function as the START button, only the first start command must
always be given at the control panel.
The following values will be displayed:
Displays the number of items which have been produced since the last “RESET”.
Press START button in Adjust-mode for resetting the counter.
Displays the amount of skipped tables since the last reset.
Shows the overall number of produced items.
Delay time for working cycle to give the operators more time to do their work.
Use turning knob “SET” to change the time.
Is displayed when production is running.
