Operating Instructions Synchroprint 5000
Operating instructions SP5000 V1-0.docx Page 15 of 52
5.4. External supply/Connection ports
Connections for compressed air and mains electricity are located on the base unit of the
Synchroprint as standard. Overhead supply connections may be ordered optionally but only at time
of order, to enable supplies to enter the machine from above, through the centre column.
5.4.1. Electrical Connections
The electrical requirements are as follows:
Description
Requirement/Value
Supply voltage
3x 210/400V
Supply frequency
50/60 Hz ± 5 %
Connected load
2.5 kVA + (0.4 kVA x “number of print heads”)
(= “power for indexer main drive” + “power per print head” x
“number of print heads”)
5.4.2. Compressed Air Requirements
Type of machine
SP 8
SP 10
SP 12
SP 14
SP 16
SP 18
SP 20
Air consumption (l/min.)
190
220
250
280
310
340
370
Minimum air pressure
8 bar / 116 PSI
Air quality
filtered, dry air supply only
(class 1:4:1 according ISO8573-1:2010)
Please observe the general safety regulations for electrical connections when
connecting the mains supply to the Synchroprint. Avoid any contact with live
components.
Danger of tripping over!
In case of laying supply lines on the floor, it is necessary to attach step covers.
All flash cure units must be supplied through a separate/independent
connection. Please observe the precise technical data from the flash cure unit
specification sheet.
