12. Maintenance of the Synchroprint
The Synchroprint has been designed to operate ‘maintenance-free’ as far as possible. Only a few
important service measures are necessary by the operator.
Remove all residues from the Synchroprint remaining
from production materials such as inks and adhesives
etc. Clean, tidy and sweep the printshop area.
Wash off all anodized parts of the Synchroprint with
an appropriate cleaner. Clean all inspection glasses
and displays. Clean or replace the protective foil on
the touch screen.
The surface must only be cleaned with a dry cloth or
appropriate monitor-cleaning cloth. If any aggressive
cleaners or solvents are applied, the surface of the
touch screen will be damaged or destroyed, resulting
in cancellation of the warranty. MHM recommends
covering the touch screen with a self-adhesive clear
protective foil, which may be applied to the actual
touch screen and taken off and renewed at any time.
Wipe clean the sealing
band on the underside of
all the linear profiles
The sealing band on the underside of the linear
profiles must be wiped clean thoroughly and
lubricated with an oil-soaked cloth.
Sealing band on
the underside of
the linear profiles
Before doing maintenance work the machine must be cut off from the supply
voltage using the main power switch).
