Operating Instructions Synchroprint 5000
Operating instructions SP5000 V1-0.docx Page 30 of 52
9. Control of the Machine
This section explains the control features of the machine from the main touch screen.
9.1. Stopping the Machine in the event of an Emergency
If the operator detects any danger to personnel or the Synchroprint, he can immediately shut down
the machine by pressing the EMERGENCY STOP push button.
On both the left and right hand side of the load/un-load stations there are two safety bars marked
yellow/black, which stop the machine immediately when actuated.
Between each print station there are safety barriers marked yellow/black. If any one of these
barriers is opened the machine will stop immediately.
This section illustrates the most important of the command screens, not all of
which may be illustrated due to the very complex software. The command
screens not illustrated in particular are those of a self explanatory nature.
There is an EMERGENCY STOP push button located on the main control
panel. The operating staff must be aware of its location in order to stop the
machine in the event of an emergency as quickly as possible.
These safety devices must not be used to switch off the machine under normal
operation. Any EMERGENCY STOP presents an exceptional loading to the
servo-motor and transmission etc. Excessive use will result in damage to the
machine along with subsequent cancellation of the warranty.
When having dangerous electrical problems the main power switch must be
used to disconnect the machine from the main supply voltage immediately.
