Easidew Online User’s Manual
Michell Instruments 5
INSTALLATION
2.1.3 Accessories Pack
The accessories pack is shown below.
1
2
3
4
Figure 5 Accessories Pack
Remove the screwdriver (1), the two leads (2) and (3) and the sample block (4) from
the bag.
2.2 Easidew Online Components
On delivery please check that all the following standard components are present in the
packing box. Report any shortages to Michell Instruments, immediately.
1
2
3
4
5
6
7
8
9
°
C
dp
°
Fdp
Easidew Online
Dew-Point Hygrometer
User’s Manual
97211 Issue 01, May 2010
Figure 6 Easidew Online Components
1. Monitor clamps (2 off)
2. Easidew Monitor
3. Transmitter cable assembly
4. Power cable
5. Screwdriver
6. User’s Manual
7. Calibration certifi cate
8. Sample block
9. Easidew transmitter
