Easidew PRO XP User’s Manual
12 97442 Issue 5, May 2018
INSTALLATION
The protective Earth terminal is mounted externally
and the Earth wire connected to it should never be
disconnected. The product enclosure is supplied with a
5mm (0.2”) diameter external Earth connection at the
lower right hand side. At installation, connect this Earth
connection to plant Earth by a minimum 4mm
2
(0.16
2
”)
earthing bonding.
This product is designed, where applicable and possible, to be in compliance with EN/
BS/IEC61010 safety requirements or electrical equipment or measurement, control,
and laboratory use. This product is designed to be safe at least under the following
conditions: between a temperature range of -5 to +40°C (+23 to +104°F), in maximum
80% relative humidity for temperatures up to +31°C (+88°F) decreasing linearly to
50% RH at +50°C (+122°F). Supply voltages of ±10% and transient over voltages
up to Overvoltage Category II. Pollution Degree 2. Altitudes up to 2000m. Outdoor
mounting is permitted using suitably rated glands equivalent to NEMA 4 / IP66. See
Appendix A, Technical Specifi cation, for full operating parameters.
NOTE: Do not remove or exchange any of the cables or electrical components
supplied with this product. Doing so will invalidate all warranties.
Refer to the relevant sections of this manual for the location and mounting details.
Installation of this equipment should include the provision of a suitable and locally
positioned power isolation switch or circuit breaker. Indication of the purpose of the
switch or circuit breaker is strongly recommended. An over-current protection device
should be rated to a maximum of 3 A.
Ensure this equipment and all power isolation devices are installed in a location and
position that allows safe and easy access to their operation and is adequate to rigidly
support the equipment.
Do not install this equipment in a location that would expose it impact or high levels of
vibration.
Operation of this equipment, other than in a manner as specifi ed by the manufacturer,
may impair the safety protections provided.
The safe installation of this equipment and any system incorporating this equipment is
the responsibility of the installer. Ensure local regulations and requirements are referred
to prior to any installation commencing.
