Easidew PRO XP User’s Manual
Michell Instruments 31
APPENDIX D
Displayed Text Description
Setting sampling rate St
Press
E button
Press
and buttons to change the sampling rate from 1 to 10
seconds
1 = Factory default
Press
E button. Press to go to Engineering Unit
Displayed Text Description
Set-up Engineering Unit
Press
E button
Press
and buttons to select the unit
- nonE - for no unit on the display (factory default setting) see D.5
- °C, °F, K, %
(There is a 6 second cycle
- measured value is displayed for 4 seconds
- the unit is displayed for 2 seconds)
Press E button
Exit from menu and save settings:
Press
and buttons (possible from each page)
C.5 Moisture Scaling Label
The Easidew PRO XP has 3 standard ranges and scales which are as follows:
EA-XP-TX -110 to +20°Cdp output range
-100 to +20°Cdp output range
EA-XP-LQ-TX 0-1000ppm
W
The EA-XP-TX units will be confi gured for the range/scale ordered (as above) and will constantly
display the measured value. The display meter will have a stick-on label defi ning the scale in °C DP.
E
Easidew PRO XP
Moisture Transmitter
°C DP
Label
If ordered with a non-standard range/scale the unit could be set up with the following:
°F DP
lbs/MMSCF
ppm
V
ppm
W
mg/m
3
Alternatively, an Easidew PRO XP Communication Kit (XP-CK) can be used to change the range/scale
and this Kit will be shipped with its own manual and 2 additional sets of scaling labels so that the
label can be changed as required.
