Microhard Systems IP-921 - Page 119

© Microhard Systems Inc. CONFIDENTIAL 119
IP9xx Series
6.0 Configuration
RADIUS Server IP
In this field, the IP address of the RADIUS server is to be entered if
RADIUS&Local has been selected as the Authorization Mode.
Values
Local
RADIUS&Local
Values
Valid RADIUS server IP
address
0.0.0.0
RADIUS Server Port
In this field, the applicable Port number for the RADIUS Server is to
be entered if RADIUS&Local has been selected as the
Authorization Mode.
Normally, a RADIUS Server uses Port 1812 for the authentication
function.
Values
Applicable RADIUS Server
Port number
1812
Auth Mode
Select the Authentication Mode: Local (default) or RADIUS&Local.
For the latter selection, RADIUS authentication must be attempted
FIRST; if unsuccessful, THEN Local authentication may be
attempted.
