IP9xx Series
6.0 Configuration
The following factors must be considered when preparing to config-
ure the modems:
 the application
 network topology
 physical distribution of the network
 data interface requirements
Components involved in the configuration process of the IP Series:
 interfacing with the modem, and
 selecting and inputting the desired operational parame-
ters
Interfacing to the IP Series for the purpose of initially configuring it
may be accomplished in one of two ways:
 front COM2 connector, Microhard Systems Inc. DE9-
RJ45 Diagnostics Cable (P/N MHS044000, black), and a
PC running terminal communications program (e.g.
HyperTerminal), or
 rear ETHERNET (RJ45) port, ethernet crossover cable,
and PC running Microhard Systems Inc. DiscoverIP util-
ity and Web Browser application.
All configuration of the IP Series is accomplished with a PC. There
are no DIP switches to set; switches which may subsequently be-
come inadvertently misadjusted or intermittent.
