IP9xx Series
3.0 Hardware Features
On the front of the IP Series are, from left to right:
 COM2 Port (DCE)
 CFG pushbutton
 TX LED
 RX LED
 SYS LED
 RSSI LEDs (3)
Image 3A: Front View of IP Series
The IP Series is a fully-enclosed unit ready to be interfaced to
external devices.
Any IP Series may be configured as a Master, Repeater (or
Repeater/Slave), or Slave. This versatility is very convenient from a
‘sparing‘ perspective, as well for convenience in becoming very
familiar and proficient with using the device: if you are familiar with
one unit, you will be familiar with all units.
3.1 IP9xx Connections
3.1.1 Front
