Microhard Systems IP-921 - Rules

© Microhard Systems Inc. CONFIDENTIAL 125
IP9xx Series
6.0 Configuration
6.1.7.7.2 Rules Configuration
Rules take precedence over Policies. They are configured to ‗fine
tune‘ firewall settings.
Action
Define the action which is to be taken by the defined rule.
Values
ACCEPT
ACCEPT+>future
NONAT>future
DROP
REJECT
DNAT
SAME>future
REDIRECT>future
CONTINUE>future
LOG
QUEUE>future
Image 6AG: Firewall Configuration, Rules Config. Submenu
