IP9xx Series
6.0 Configuration
6.1 Web User Interface
Initial configuration of an IP Series using the Web User (Browser)
Interface (Web UI) method involves the following steps:
connect IP Series ETHERNET port to PC NIC card using an
ethernet crossover cable
apply power to the IP Series and wait approximately 1 minute
for the system to load
run Microhard Systems Inc. DiscoverIP Utility on the PC (see
Appendix A for complete details on this convenient utility)
within the DiscoverIP Utility window, click on the desired unit‘s
IP address (verify displayed MAC address with MAC address
printed on sticker on bottom of unit)
logon window appears; log on
configure IP Series as desired.
In this section, all aspects of the Web Browser Interface, presented
menus, and available configuration options will be discussed.
The modem will arrive from
the factory with DHCP
enabled and a unique random
Class D IP address.
The DiscoverIP utility is
utilized to ‘discover‘ the IP
address of the IP Series (not
other devices on network) so
that you may specifically
address it (in Web Browser
URL line) for configuration
purposes.
