IP9xx Series
6.0 Configuration
Select Service
This field allows for the rule to be applied to either a Custom
Service (defined further down the menu) or for one of many
predefined services available via a pulldown menu.
Values
Custom Service
or select from a long listing
of predefined services
Destination IP
If a valid IP address is specified, the action will apply against that
address; otherwise, leaving the default value of 0.0.0.0 in this field
results in the action applying to all destination IP addresses.
Values
0.0.0.0
valid IP address
Destination Port
This field is configured if defining a Custom Service (ref. Select
Service field).
Values
0
valid port number
