IP9xx Series
2.0 Quick Start
 Select Option B: Network Configuration, then
 A: Local IP Config, then
 A: IP Address Mode, then
 A: static
 Input suitable (for your PC/network) values for:
 IP Address
 Subnet Mask
 Gateway
 Press U to SAVE the configuration changes.
 Press [Esc] twice to return to the MAIN MENU.
 Select Option C: Radio Configuration, then
 B: Operation Mode, then
 A: Master, then
 I: Network Type, then
 B: Point-to-Point, then
 J: Destination Unit, then
enter the number 20 [Enter]
 Press U to SAVE the configuration changes.
 Press [Esc] to return to the MAIN MENU.
 Press Q to Quit.
The IP Series configured above is now the MASTER IP Series for
your Point-to-Point IP Series network.
Remove the connection from the MASTER IP Series‘s COM2 port
and move it to the other IP Series.
 Press [Enter]
 A login prompt will appear. Enter admin.
 At the password prompt, enter admin.
continued...
View the PC‘s NETW ORK
SETTINGS (TCP/IP Properties) to
determine an appropriate IP
Address, Subnet Mask, and
Gateway for the IP Series.
(For basic testing, the Gateway
value is not critical.)
If a connection is being made to a
network (LAN), check with the
Network Administrator for an
available static IP address(es) so
as not to potentially create an IP
address conflict.
