IP9xx Series
6.0 Configuration
New Binding MAC
In this field, input the MAC address (in specified format) of the
device to which a specific IP address is to be bound.
For the IP Series, the MAC address of the unit may be found on the
label on the bottom of the unit, or it may be viewed on the Network
Configuration menu of that unit.
00:00:00:00:00:00
MAC address of target
device
An address binding is a
mapping between a specific
IP address and the MAC
address of a specific client.
New Binding IP
Enter the IP address - from within the range identified with the
Starting Address and Ending Address parameters input previously -
which is to be ‗bound‘ to the MAC address identified in the New
Binding MAC field (described above).
0.0.0.0
IP address from within range
identified in Starting Address
and Ending Address fields
Values
Values
