IP9xx Series
6.0 Configuration
Image 6T: Repeater Registration
Repeater Registration
In order to ensure that generated hopping patterns are orthogonal
to each other (thereby minimizing possible interference between
network segments), if there is more than 1 Repeater in a network,
ALL Repeaters must be registered in EVERY IP Series.
The following image depicts an example:
In the above example, there is a total of 3 Repeaters in the system,
with Unit Addresses of 7, 18, and 25. Again, these Repeater UAs
must be added into each/every IP Series‘s Repeater Registration
field.
Format:
x,y,z
where
x, y, and z are Repeater UAs,
