Microhard Systems IP920 User Manual

4 IP920 Operating Manual: Chapter 2 Electrical/Physical
2. Electrical/Physical
2.0 Connectors
The IP920 connects to the host equipment through a standard DB9 serial port
or RS485/422 interface. All connectors and indicators are illustrated in
Figure 1
Microhard Systems Inc.
COM2
CFG TX RSSI
RX SYS
a. Front Panel
ETHERNET
COM1
Vin +
GNG
RxA RxB
TxA TxB
RS485/422
654321
b. Back Panel
Figure 1 Connectors and Indicators
The interface connectors and indicator lights are described below:
