12 IP920 Operating Manual: Chapter 3 User Interfaces
3. User Interfaces
For security purpose, there is no
way to reset password into a
default password, therefore system
will become inaccessible if the
password is lost.
3.0 Overview
The IP920 modem can be easily configured to meet a wide range of needs
and applications. There are three approaches which can be used to access
and configure an IP920.
1. Serial console. COM2 is assigned to system console by default.
2. Web user interface. One can access the system through an embedded
web server inside the IP920 once the IP address is determined.
3. SNMP network management. Simple Network Management Protocol
(SNMP) is another alternative for a network administrator to access the
IP920 system wide.
3.1 Notation
In textUI and webUI, different notations can tell what to expect or what to
do,
“:”–– An item with colon is an item that can be edited or is just for
display;
“…”–– An item with “…” is an item that has submenu or multiple
choices.
3.2 Serial Console
COM2 is used as a system console by default, it can also be used as a second
data port if desired. When used as a console port, the port is configured as
follows,
Baud Rate: 115,200
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control: None
Make sure the terminal software has same settings as shown above. The
textUI is designed to adapt to any type of terminal, however a VT100 or
ANSI terminal type is recommended for better operation.
User name and password are needed to login to the system. Only the
administrator can login to the system to access the textUI through the
console. Default user name and password are as follows,
IPx20 Login: admin
Password: admin
Password can be changed via user interface. Note that user name and
password are case sensitive. For security purpose, there is no way to reset
password into a default password, therefore system will become inaccessible
if the password is lost.
