14 IP920 Operating Manual: Chapter 3 User Interfaces
An IP920 discovery program
can be found from website:
www.microhardcorp.com
.
This program helps to find a
dynamic IP address
associated to a IP920.
For security purpose, DO NOT let
the web browser remember user
name and password.
3.3 Web Based User Interface
To make life easier, webUI will be used in following sections instead of a
web based user interface.
Once an IP address is assigned to an IP920 unit, dynamically or statically,
webUI can be accessed using any web browser, such as IE, Netscape and
Mozilla, etc. from a host machine.
If the IP address is 192.168.1.100, simply typing in the following syntax on
the address bar in a favorite browser can bring up the webUI.
http://192.168.1.100
Before the main page show up, user name and password are needed to login
to the system. Default user name and password are the same as textUI.
Figure 3 webUI Authentication
Figure 4 webUI Screen Shot
