52 U3000/U4000 User Manual
(Issue 2.0)
TRANSDUCER SETS
Standard: Temperature Range -20°C to +135°C.
'A-ST' (standard) 13 mm…115 mm pipe O.D.
'B-ST' (standard) 50 mm…2000 mm pipe O.D.
Protection: IP54 standard, IP67 optional
High Temperature: Temperature Range -20°C to +200°C
'A-HT' (High Temp) 13 mm…115mm pipe O.D.
'B-HT' (High Temp) 50 mm…2000mm pipe O.D.
Optional: Temperature Range -20°C to +80°C (0.5MHz).
'D' 1500 mm…5000 mm pipe O.D.
DATA LOGGER (U4000 only)
Data Logged: Standard: All measurement parameters and flow reading
Optional: Totalised values
No. data points: Standard: 98K data points (may be affected by totaliser)
Optional: 196K data points (may be affected by totaliser)
Time Stamping: All data points are date & time stamped.
No. Sites: 1 (non-editable) and 1 (editable)
Logging Interval: User programmable 5 secs to 1hr
Operating Modes: Logging stopped when memory full
Logging continues on memory overflow with old date overwritten.
Logged Data Transfer: Logged data can be transferred to PC via RS232 or USB
LANGUAGES
Standard Supported Languages: English, French, German, Italian, Spanish, Portuguese, Russian, Norwegian, Dutch,
Swedish.
OUTPUTS
Serial Interface: RS232 and USB 2.0
Full Speed (12Mbits/sec) mode, USB software driver provided.
Logged Data Can be output to PC or Printer
Current Output:
No. Channels
Format:
Resolution:
Error Currents:
Isolation:
Maximum Load:
1
4–20mA, 0–20mA, 0–16mA.
0.1% of full scale.
Any between 0–26mA.
1500V Opto-isolated from unit.
620 Ohms.
Pulse Output TTL:
Number Available:
Isolation:
Pulse Repetition Rate:
Pulse Width:
Max Current:
Max Voltage:
1 – Opto-isolated MOSFET relay.
1500V opto isolated from unit.
User programmable from 1 to 250 ppm.
User programmable from 2ms to 500ms.
500mA.
48V
