Page #37 background imageLoading...
Page #37 background image
4: Data Logging & Communications (U4000)
U3000/U4000 User Manual 33
(Issue 2.0)
Stop logging
1. From the FLOW READING screen, press
the Logger function key to access the
REAL TIME LOGGER screen.
2. Select STOP NOW to cease logging.
Note that the START NOW and STOP NOW
options toggle depending on which was last
selected.
3. Select Exit to return to the FLOW
READING screen.
4. Note that the logged data will remain stored
in the instrument’s memory and can be
accessed at any time as described above.
4.2 How To Set Up Automatic (Timed) Logging Mode
This procedure shows you how to set up an auto logging session under timed start/stop control. The logged
data is saved to the instrument’s memory and can be downloaded to a PC at a later time.
Starting point
This procedure assumes that the instrument has been correctly installed and is operating in the FLOW
READING mode. Also that the instrument’s date and time are correctly set.
Setting up, starting and cancelling auto logging
1. With the U4000 instrument operating in FLOW READING mode, check that the indicated flow units are the
same as those you want to appear on the logger output (e.g. l/min).
2. Press the Logger function key to access
the REAL TIME LOGGER screen.
3. Select Log data to and choose Memory.
This will store the log to the internal
memory.
4. Select Logging interval and enter the
required period (e.g. 10 seconds).
5. Select Log Totals to log either +Totals,
–Totals or Both.
6. Select Start date & time and enter the
date and time you wish logging to
commence. Note this must be in the future.
7. Select Stop date & time and enter the
date and time you wish logging to cease.
Note this must be later than the start time.
Key Point: When entering the Start and Stop times in this procedure, you must
enter ‘00’ in the seconds field rather than leave it blank, otherwise an error message
is displayed.
REAL TIME LOGGER DD-MM-YY HH:MM:SS
Dim: mm
Unit : l/min
Log name : Quickstart
Log data to : Memory
Logging interval : 10 seconds
Start date & time : dd-mm-yy hh:mm:ss
Stop date & time : dd-mm-yy hh:mm:ss
MM DD HH MM SS
Remaining time : mm dd hh mm ss
Memory Rollover : Overwrite
Graph Y axis max. : 50
Log Totals : +Total
View log as text
View log as graph
STOP NOW
Set Auto start
Clear log
Exit
REAL TIME LOGGER DD-MM-YY HH:MM:SS
Logging to Memory Dim: mm
Unit : l/min
Log name : Quickstart
Log data to : Memory
Logging interval : 10 seconds
Start date & time : dd-mm-yy hh:mm:ss
Stop date & time : dd-mm-yy hh:mm:ss
MM DD HH MM SS
Remaining time : mm dd hh mm ss
Memory Rollover : Overwrite
Graph Y axis max. : 50
Log Totals : +Total
View log as text
View log as graph
START NOW
Set Auto start
Clear log
Exit
