Midas MR18 User Manual

11 M AIR User Manual
3.2.2 MR12 System Overview
Router
ETHERNET mode
Computer with Ethernet port
Mobile Devices with WiFi
CAT-5 cable
Win/Mac/Linux
iOS/Android
or
MIC/LINE IN
STEREO REC
(VARIOUS SOURCES)
STEREO PLAY
(SPECIFIC “USB”
STEREO
INPUT CHANNEL)
MAIN OUT L-R
AUX SEND 1-2
ETHERNET
Hi-Z
LINE IN
PHONES STEREO
AUDIO INPUTS
USB RECORDER
AUDIO I/OMIXER CONTROL
DSP ENGINE
MR12
MIDI I/O
WIRED CONTROL
ACCESS
POINT*
WIFI
CLIENT*
WIRELESS
CONTROL
AUDIO OUTPUTS
LEVEL
DSP
ACCESS POINT
WIFI CLIENT
ETHERNET
Router
WIFI CLIENT mode (Mobile Devices with Wi)
ACCESS POINT mode (Mobile Devices with Wi)
iOS/Android*
*ACCESS POINT mode:
- available channels: 1-11
- max. 4 Wi clients
- bandwidth limited by Wi adapter
*WIFI CLIENT mode:
- available channels: 1-11
*Ch. 13-16 fed by any IN 1-12
(Signal Split, e.g. for
monitoring with dierent EQ)
*PRE-DEFINED BUSES
Also used for monitoring
4 STEREO FX SLOTS
DSP-MIXER CH.
MONO IN 1-16
USB/AUX IN (STEREO)
FX RETURN 1-4 (STEREO)
DSP-MIXER BUSES
PRE-DEFINED AS SUBGROUPS*
XR12: BUSES 3/4/5/6
XR16: BUSES 5/6
Win/Mac*/Linux*
iOS/Android Android
Win/Mac/Linux
DACs
DACs
4 STEREO FX SLOTS
DSP-MIXER CH.
MONO IN 1-16*
USB/AUX IN (STEREO)
FX RETURN 1-4 (STEREO)
DSP-MIXER BUSES
PRE-DEFINED AS SUBGROUPS*
MR12: BUSES 3/4/5/6
ADCs
RTA METER
DACs
ADCs
CAT-5 cable
X-TOUCH
or any other MIDI /
Mackie Control
compatible Controller

Midas MR18 Specifications

General

Channels	18
Mic Preamps	16
Aux Sends	6
Sample Rate	48 kHz
Type	Digital Mixer
EQ Bands	4-band parametric
Data I/O	Ethernet
Computer Connectivity	USB
MIDI I/O	No
Headphones	1 x 1/4"
A/D Resolution	24-bit
Bit Depth	24-bit
Phantom Power	Yes
Inputs	16 x XLR/TRS Combo, 2 x 1/4"
Digital Signal Processing	40-bit
Frequency Response	20Hz - 20kHz
Connectivity	Ethernet
Control	Ethernet, Wi-Fi
Effects	Reverb, delay, chorus, flanger, phaser
USB Audio Interface	Yes
