V6 VRF 50/60Hz
4
Midea V6 Series Service Manual
1 Indoor and Outdoor Unit Capacities
1.1 Indoor Units
1.1.1 Standard indoor units
Table 1-1.1: Standard indoor unit abbreviation codes
Abbreviation
code
Type
Abbreviation
code
Type
Q1 One-way Cassette T1 High Static Pressure Duct
Q2 Two-way Cassette G Wall-mounted
Q4C Compact Four-way Cassette DL Ceiling & Floor
Q4 Four-way Cassette F Floor Standing
T2 Medium Static Pressure Duct Z Console
Table 1-1.2: Standard indoor unit capacity range
Capacity
Capacity
index
Q1 Q2 Q4C Q4 T2 T1 G DL F Z
kW HP
1.8 0.6 18 18
— — — — — — — — —
2.2 0.8 22 22 22 22
—
22
—
22
—
22 22
2.8 1 28 28 28 28 28 28
—
28
—
28 28
3.6 1.25 36 36 36 36 36 36
—
36 36 36 36
4.5 1.6 45 45 45 45 45 45
—
45 45 45 45
5.6 2 56 56 56
—
56 56
—
56 56 56
—
7.1 2.5 71 71 71
—
71 71 71 71 71 71
—
8.0 3 80
— — —
80 80 80 80 80 80
—
9.0 3.2 90
— — —
90 90 90 90 90
— —
10.0 3.6 100
— — —
100
— — — — — —
11.2 4 112
— — —
112 112 112
—
112
— —
14.0 5 140
— — —
140 140 140
—
140
— —
16.0 6 160
— — —
160 160 160
—
160
— —
20.0 7 200
— — — — —
200
— — — —
25.0 9 250
— — — — —
250
— — — —
28.0 10 280
— — — — —
280
— — — —
40.0 14 400
— — — — —
400
— — — —
45.0 16 450
— — — — —
450
— — — —
56.0 20 560
— — — — —
560
— — — —
1.1.2 Fresh air processing unit
Table 1-1.3: Fresh air processing unit capacity range
Capacity 12.5kW 14kW 20kW 25kW 28kW 45kW 56kW
Capacity index 125 140 200 250 280 450 560
Table 1-1.4: Small airflow rate fresh air processing unit capacity range
Capacity 14kW 22.4kW 28kW
Capacity index 140 224 280
1.2 Heat recovery ventilator
Table 1-1.5: Heat recovery ventilator capacity range
Airflow rate 200m
3
/h 300m
3
/h 400m
3
/h 500m
3
/h 800m
3
/h 1000m
3
/h 1500m
3
/h 2000m
3
/h
