Midea V6 Series Service Manual
1 Outdoor Unit Field Settings
1.1 PCB Switches and Switch Settings
Figure 4-1.1: Outdoor unit main PCB switches
Table 4-1.1: Outdoor unit main PCB switch settings
S4
Static pressure
External Static Pressure is 0Pa (default)
External Static Pressure is 20Pa (customize)
External Static Pressure is 40Pa (customize)
External Static Pressure is 60Pa (customize)
External Static Pressure is 80Pa (customize)
External Static Pressure is 100Pa (customize)
External Static Pressure is 120Pa (customize)
S5
Priority mode
2
Auto priority (default)
Cooling priority
VIP priority or voting priority
Heating only
Cooling only
Set priority mode via centralized controller
Table continued on next page …
