Midea MV6-252WV2GN1 - 3 Outdoor Unit Combinations

V6 VRF 50/60Hz
8
Midea V6 Series Service Manual
3 Outdoor Unit Combinations
Table 1-3.1: Outdoor unit combinations
System capacity
Number
of units
Modules
1
Outdoor branch
joint kit
2
kW
HP
8
10
12
14
16
18
20
22
24
26
28
30
32
25.2
8
1
●
—
28.0
10
1
●
33.5
12
1
●
40.0
14
1
●
45.0
16
1
●
50.0
18
1
●
56.0
20
1
●
61.5
22
1
●
67.0
24
1
●
73.0
26
1
●
78.5
28
1
●
85.0
30
1
●
90.0
32
1
●
95.0
34
2
●
●
FQZHW-02N1E
101.5
36
2
●
●
106.5
38
2
●
●
112.0
40
2
●
●
117.5
42
2
●
●
123.0
44
2
●●
128.5
46
2
●
●
134.5
48
2
●
●
140.0
50
2
●
●
146.0
52
2
●●
151.5
54
2
●
●
157.0
56
2
●●
163.5
58
2
●
●
168.5
60
2
●
●
175.0
62
2
●
●
180.0
64
2
●●
185.0
66
3
●
●
●
FQZHW-03N1E
191.5
68
3
●
●
●
196.5
70
3
●
●
●
202.0
72
3
●
●
●
207.5
74
3
●
●
●
213.0
76
3
●●
●
218.5
78
3
●
●
●
224.5
80
3
●
●
●
230.0
82
3
●
●
●
236.0
84
3
●●
●
241.5
86
3
●
●
●
247.0
88
3
●●
●
253.5
90
3
●
●
●
258.5
92
3
●
●●
265.0
94
3
●
●●
270.0
96
3
●●●
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also available.
2. For systems with two or more outdoor units, outdoor branch joints (sold separately) are required.
