Midea V6 Series Service Manual
5 Normal Operation Control
5.1 Component Control during Normal Operation
Table 3-5.1: Component control during normal cooling operation
Component
Wiring
diagram
label
8-12HP 14-16HP 18-28HP 30-32HP Control functions and states
Inverter compressor A
COMP(A)
● ● ● ●
Controlled according to load requirement
Inverter compressor B
COMP(B)
● ●
DC fan motor A
FANA
● ● ● ●
Controlled according to discharge pressure
DC fan motor B
FANB
● ●
E
lectronic expansion valve
A
EXVA ● ● ● ●
Position (steps) from 0 (fully closed) to 480 (fully
open), controlled according to discharge
temperature
E
lectronic expansion valve
B
EXVB ● ● ●
E
lectronic expansion valve
C
EXVC ● ● ● ●
Position (steps) from 0 (fully closed) to 480 (fully
open), controlled according to temperature
different between plate heat exchanger inlet and
outlet
Four-way valve
ST1
● ● ● ●
Off
Solenoid valve (oil balance) SV4 ● ● ● ●
Open regularly
Solenoid valve (fast
defrosting (in heating) and
unloading (in cooling))
SV5 ● ● ● ●
C
ontrolled according to ambient temperature,
discharge pressure, discharge temperature,
compressor running frequency and discharge
superheat
S
olenoid valve (EXV
bypass)
SV6 ● ● ● ●
Controlled according to discharge pre
ssure and
discharge temperature
S
olenoid valve (indoor
units bypass)
SV7 ● ● Controlled according to load requirement
Solenoid valve (inverter
c
ompressor A vapor
injection)
SV8A ● ● ● ●
Controlled according to inverter compressor A
on/off
Solenoid valve (inverter
compressor B vapor
injection)
SV8B ● ●
Controlled according to inverter compressor B
on/off
Solenoid valve (inverter
compressor B pressure
balance)
SV9
● ●
Open before compressor B startup and close after
compressor B running for 15 seconds. Open after
compressor B stop 10 seconds and keep open 60
seconds.
